SMA Sunny Tripower X12

The SMA Sunny Tripower X 12 - for both residential and commercial use

The SMA Sunny Tripower X series has a new System Manager function. Up to 5 SMA inverters can be integrated up to a total system output of up to 135 kVA. Direct marketing via SMA Spot without Data Manager M can be implemented within this system. The Sunny Tripower X inverter has a direct connection for the radio ripple control receiver (FRE). An external section switch is no longer required for central NS protection in the low-voltage level.

product benefits

• Integrated section switch for central NA protection already available
• Integrated connection for radio ripple control receiver (FRE).
• Compatible with SMA Energy App, 360° App, Sunny Portal, SHM 2.0, Data Manager
• Arc Flash Protection Function (AFCI)
• Direct marketing via SMA SPOT up to 135 kVA
• Integratable DC ÜSS Type 2 or Type 1+2

product properties

• Mains connection: 3-phase
• AC Rating: 12kVA
• MPP tracker: 3
• String connections per MPPT: 2
• Max. short-circuit current per MPPT: 35 A
• Communication: Ethernet, WiFi
• Number of digital inputs: 6 pieces (for FRE)
• Protection class: IP 65
• Dimensions: 762 x 728 x 266 mm (H x W x D)
• Weight: 35.0kg

Downloads

• SMA Sunny Tripower X 12 data sheet
• SMA Sunny Tripower X Flyer
