SMA Sunny Tripower 50-41 CORE 1

The commercial inverter Sunny Tripower CORE 1 STP 50-41 from SMA

The SMA Sunny Tripower CORE1 is the first 50 kW string inverter from SMA that can be installed free-standing. With his 6 MPP trackers the CORE1 is based on the successful Sunny Tripower technology and is therefore ideal for decentralized roof and open spaces as well as covered parking spaces. Commercial PV installations can be implemented quickly and easily. The Sunny Tripower 50-41 CORE1 differs from the Sunny Tripower 50-40 CORE1 due to two new functions. On the one hand it contains the arc protection function AFCI and on the other hand it is equipped with an IV generator diagnosis.

product benefits

• Integrated DC disconnect switch
• Arc protection function AFCI
• PV generator IV diagnosis
• Central NA protection using network guard and I/O interface
• Connection of the FRE to the I/O interface of the inverter

product properties

• Rated power: 50 kW
• AC nominal voltage: 230/ 400 V
• 6 MPP trackers each with 2 DC inputs and Sunclix connectors
• Integrated WiFi and Ethernet
• Device status via LED display, no display
• Protection class: IP 65
• Product guarantee: 5 years
• Dimensions: 621 x 733 x 569mm
• Weight: 84kg

Together with the SMA Datamanager M you can monitor several SMA inverters in the SMA Sunny Portal. It also forms the interface for direct marketing.

The STP50-41 from SMA is the ideal PV inverter for commercial PV systems when comprehensive cost savings are required. Fast installation, flexible design and service from SMA are the best arguments for this 50 kW inverter.

Downloads

• SMA CORE1 data sheet
• SMA CORE1 Operating Manual

Required accessories

SMA Sunny Tripower CORE 1 I/O interface

Ziel NA protection guard UFR1001E
