SMA Hybrid Sunny Tripower 5.0 Smart Energy

The SMA hybrid inverter STP 5.0 SE for HV batteries

The SMA Sunny Tripower Smart Energy is a hybrid inverter that is intelligently networked with the SMA energy management system. With a Sunny Home Manager 2.0, heat pumps and e-charging stations can be integrated in addition to the battery. With forecast-based charging, you increase the efficiency of the overall system and charge the battery during lunchtime.

product benefits

• Compatible with SMA Sunny Home Manager 2.0
• Integrated switching device for backup power
• Compatible with SMA Energy App, 360° App and Sunny Portal
• Also stores the energy from other PV inverters or a CHP
• AC and DC ÜSS type 2 integrated

Product features SMA Hybrid STP 5.0 SE

• Mains connection: 3-phase
• AC Rating: 5kVA
• Max. power in emergency power mode: 10 kVA (max. 10 s)
• MPP tracker: 2
• String connections per MPPT: 1
• Communication: WLAN, Ethernet, CAN
• Incl. 3 m battery cable with MC4 connectors
• Typical noise emissions: 30 dB (A)
• Protection class: IP 65
• Dimensions: 598 x 500 x 173 mm (H x W x D)
• Weight: 30.0 kg

battery compatibility

Solar ranch power storage release list

Downloads

• SMA Sunny Tripower 5.0 Smart Energy data sheet
• SMA Sunny Tripower Smart Energy quick start
• SMA Sunny Tripower Smart Energy Operating Manual

Required accessories

SMA Sunny Home Manager 2.0
