GoodWe ET Plus - GW8K-ET

This three-phase hybrid inverter has a three-phase, three-phase backup power output. Together with the high-voltage battery connection and 2 independent MPP trackers, the GoodWe inverter leaves nothing to be desired. This device is configured up to date via the GoodWe PV Master app and sends its data to the free GoodWe SEMS portal via the integrated WiFi interface. The scope of delivery already includes a three-phase smart meter with folding current transformers. The ET Plus series has a programmable potential-free contact. This allows additional consumers such as wall boxes and heat pumps to be integrated. Will he GoodWe EV charger integrated, communication takes place via the SEMS portal.

product benefits

• Integrated switching device for backup power
• Black start capable
• AC charging, expandable via the SDT G2 series, among other things
• High efficiency of up to 98.2%
• DC ÜSS Type 2 integrated
• Direct connection to ripple control receiver
• Cascade operation of several ET devices with accessory SEC1000S Hybrid Combinerbox (Memodo 4407) possible!

Product features GoodWe GW8K-ET

• Mains connection: 3 phases
• AC Power: 8.0kVA
• 8.0 kW emergency power output via separate output
• MPP trackers: 2
• String connections per MPPT: 1
• Battery connection for high-voltage battery (BYD, GoodWe)
• RS485, WLAN (optional LAN)
• Potential-free contact available (programmable via SolarGo app) (SG-Ready)
• Push-in terminals for the communication interfaces simplify installation
• 3-phase smart meter included
• Dimensions: 516 x 415 x 180mm (HxWxD)
• Protection class: IP66
• Weight: 24kg
